5M0001N

PalletPro130XP

5-1/8" Coil Nailer

SHARE Facebook Share Twitter Share Linkedin Share Print

PalletPro™130XP has the power and durability to consistently drive up to 5-1/8" x .148 nails all day long. The included T-handle helps comfortably maneuver and securely control the tool during operation. The high capacity magazine holds up to 225 fasteners, ensuring maximum productivity for a wide variety of applications, such...

PalletPro130XP

5-1/8" Coil Nailer

Manual Parts Chart

Features

1

Strengthened Driver and Piston Bumper

Improve performance and durability

2

Heavy-duty threaded T-handle

For extra stability when needed

3

High Capacity Magazine

Holds up to 225 fasteners

4

Flexible collation deflector and debris shield

Protects the operator and tool when in use

5

Ergonomic Overmolded Grip

Reduces fatigue and increases control of the tool

Applications

Heavy-duty Pallet Construction
Pallet Repair
Crate and Box Assembly.
Sheathing
Decking
Subflooring

SPECIFICATIONS

Item #: 5M0001N
Tool Weight: 13 lbs (5.9 kgs)
Height: 18" (457 mm)
Length: 13" (330 mm)
Width: 6.6" (168 mm)
Warranty: 5 years
Technology: PNEUMATIC
Trigger Type: Sequential Actuation

Capacity: 120 - 225
Diameter: 0.12" - 0.148"
Range: 3" - 5-1/8"
Power Type: Pneumatic
Operating Pressure: 70 - 120 PSI (4.9 - 8.3 Bar)
Air Consumption: 11.4 SCFM
Air Inlet NPT: 3/8"
Includes: Wrenches, Tool Oil

FASTENERS

Compatible Fasteners

Type: 15° Smooth Shank Coil Nails
Degree: 15°
Range: 3" - 5"
Collation: 15° Angled Wire Coil

Type: 15° Screw Shank Coil Nails
Degree: 15°
Range: 3
Collation: 15° Angled Wire Coil

Type: 15° Ring Shank Coil Nails
Degree: 15°
Range: 3
Collation: 15° Angled Wire Coil
